Leica DT100 precision locator

Precision location for cables and pipes

Top Features

  • Precise cable location up to 11 m depth
  • Interference-free thanks to intelligent signal processing (50 Hz–200 kHz)
  • Peak / Zero / Twin / Sweep – all important location modes on board
  • Robust & lightweight: only 2.1kg
  • Long battery life: up to 15 hours
  • Bluetooth for digital documentation

Technical Data

Battery AAA 2 x 1.5 V
Data interface Bluetooth® 6, NFC
App for iOS / Android
Laser class 2
Range 0.05 up to 150m
Protection class IP65
Tolerance ±1.5mm
Units of measurement m, ft, in
Weight 2100g
Dimension 680 x 147 x 326mm
Product Number (PID) 27528000

Highlights at a Glance

  • Greater safety: Minimises the risk of hitting pipes and accidents
  • Lower costs: Prevents damage, repairs and contractual penalties
  • Greater efficiency: Reduces downtime and speeds up work processes
  • Better planning: Clear marking and documentation for a clear overview of the network
  • The removable GNSS device can be used flexibly as a standalone solution, keeping your investment future-proof.
  • Whether in construction & civil engineering, utilities or surveying: the Leica DT100 is the ideal support when it comes to working precisely and avoiding interruptions
  • Leica DT100 – because safety starts below the surface

Description

Leica DT100 – Precise pipe location for maximum safety on the construction site

Anyone digging on a construction site needs certainty – not guesswork. The Leica DT100 is your reliable locating device for finding underground cables and pipes quickly, safely and accurately. This protects people, machines and infrastructure – and avoids costly surprises.

In combination with the DE100 signal transmitter, power lines, communication cables, gas and water pipes are reliably located, clearly marked and neatly documented. This gives you maximum control during planning and ensures smooth project processes. The DE100 signal transmitter is optionally available with article number 27529000.

Scope of Delivery

Leica DT100 Precision Locator
2x Li-Ion battery for DT100
Alkaline adaptor for DT100
Li-Ion battery charger for DT100
Power Cord Adapters Type A/C/G/I
