NESTLE NLS 24 levelling device, 24x magnification, IP65
Robust and reliable NESTLE premium class!
Top Features
-
Fine adjustment by the magnetically damped compensator.
-
The knobs are easy to reach.
-
Waterproof (IP65)
Variants
Execution
Magnification
Technical Data
| Accuracy to 1 km double levelling | ± 2.0 mm |
|---|---|
| Compensator | magnetically damped |
| Shortest target distance | 0.65 m |
| Dragonfly | 8' / 2 mm |
| Dimensions / Weight | 220 x 140 x 150 mm / 1.700 g |
| Multiplication constant | 100 |
| Lens aperture | 36 mm |
| Protection class | IP65 |
| Sub-circle | 400 gon |
| Tolerance compensator | < 0.3 " |
| Product Number (PID) | 15010001 |
Highlights at a Glance
-
Horizontal angle measurement
-
Determination of the height difference between several points.
-
Optical distance measurement by means of two distance lines
-
Stake out the height of a point
-
Very good appearance with above-average workmanship.
-
Housing base made of aluminium, cover and rotary knobs made of plastic
Description
The levels of the NLS premium series are predestined for construction and engineering. The high-precision, magnetically damped compensator, the robust all-metal construction and the bright optics make the NLS an absolute professional tool. The HZ circle is smoothly adjustable, the fine lateral movement works endlessly and can be conveniently operated from both sides.
Scope of Delivery
Levelling device NESTLE NLS 24
Cord plummet, adjustment tool, operating instructions, case.
