GeoMax Receiver ZRB90 Basic
Reliable entry-level receiver with acoustic and graphic display
Top Features
-
Operation temperature -10°C to +50°C.
-
Suitable for all Zone rotating lasers.
-
Audible and graphic display.
Variants
Variant
Function
Technical Data
| Operation temperature | - 10°C to + 50°C |
|---|---|
| Reception | acoustically and graphically |
| Detection zone | 80 mm |
| Weight | 255 g |
| Dimensions | 155 x 70 x 25 mm |
| Numeric | no |
| Precision levels | ± 1, ± 2 mm |
| Reach | Ø 600 m |
| Protection class | IP66 |
| Product Number (PID) | 27405000 |
Highlights at a Glance
-
Double-sided display with graphics and sound signal.
-
Two precision levels can be selected.
Description
The GeoMax Zone series includes a total of four laser receivers that complement and enhance the performance of the Zone rotating lasers. The ZRB90 is the entry-level receiver in the Zone series and offers a robust housing as well as a double-sided display with graphics and sound signal. The 1 mm / 2 mm accuracy makes it easy to locate the laser beam and works smoothly up to 300 m. The power supply works via standard AA alkaline batteries.
Scope of Delivery
GEOMAX Receiver ZRB90 basic
Holder
Batteries
