| Operation temperature | - 20°C to + 50°C |
|---|---|
| Accuracy laser plummet | ± 1.0 mm / 1.5 m |
| Accuracy angle measurement | 5 " |
| Weight | 4300 g |
| Shortest target distance | approx. 100 cm |
| Dimensions | 153 x 175 x 340 mm |
| Lens aperture | Ø 45 mm |
| Protection class / laser class | IP54 / 2 |
| Enlargement | 30x |
| Product Number (PID) | 15104000 |
This lightweight, robust and very accurate electronic theodolite with an accuracy in angle measurement of 5" is particularly suitable for construction surveys. The DT-405 is also ideally suited for demanding tasks such as angle checks, alignments, inclinations and short levellings due to its excellent workmanship and easy operation. In addition, the DT-405L version is equipped with a visible laser plummet. This makes accurate set-up over a point easier than ever before.
