NESTLE PULSAR HV-R

Easy handling with highest precision

Top Features

  • Including laser receiver PDRG95 with mm display.
  • Set up, switch on, let's go! No tedious adjustment.
  • Complete package with receiver and target plate.
  • Sturdy aluminium housing
  • High visibility

Variants

Execution

Variant

Technical Data

Working range Ø 600 m
Operating time 20 Hours
Weight 3000 g
Laser diode / colour 635 nm, class 2 / red
Dimensions 215 x 190 x 210 mm
Tilt ± 8% two axes simultaneously
Rotation speed 0; 60; 120; 300; 600 Rpm
Protection class IP65
Self-levelling range ± 5°
Temperature range HV-R -20 °C to +50 °C
Tolerance (Defined at 25°C in horizontal application) ±1 mm per 10 m
Product Number (PID) 16016001

Highlights at a Glance

  • Highest quality standards in processing.
  • Integrated laser diode significantly increases visibility indoors.
  • Working range with receiver Ø 600 m
  • The laser can also be operated vertically.

Description

The PULSAR HV-R is a robust yet accurate multifunction laser with three working modes: rotation, scan line and point mode. In addition, the HV-R can be conveniently tilted manually in two axes by up to ± 8%. Its intuitive operating concept and robust workmanship make it easy to handle. The switchable tilt function, which stops the laser in the event of vibrations or shocks, prevents incorrect measurement results. The HV-R can also be used vertically. Complete package with remote control, including laser receiver PDRG95 with mm display, unique in this class!


Further compact information:

Info case PULSAR

Scope of Delivery

Pulsar HV-R
Laser receiver PDRG95 with clamp
Carrying case
Target board
Wall mount
Charger
Remote control
Laser goggles

Request
